Product Description:
The switch has a MAC Address Table of 8K, which allows for efficient handling of network traffic. This table can store the MAC addresses of all connected devices, allowing for quick and efficient routing of data packets. The switch also supports 10BASE-T network media, which is compatible with UTP Category 3, 4, and 5 cables with a maximum length of 100m.
The Gigabit Smart Switch is also designed to operate in a wide range of environments. It has an operating temperature of 0℃~45℃ (32℉~113℉), making it suitable for use in most indoor environments.
The switch is a smart managed switch, which means it has advanced features that allow for easy management and configuration. These features include VLAN, QoS, IGMP Snooping, and Link Aggregation Control Protocol. VLAN allows for the creation of separate virtual networks, while QoS ensures that important data is given priority over less important traffic. IGMP Snooping allows for efficient handling of multicast traffic, while Link Aggregation Control Protocol allows for the creation of link aggregation groups to increase bandwidth and redundancy.
In conclusion, the Gigabit Smart Switch is a versatile and reliable switch that is ideal for both home and small business use. With its advanced features, it can provide efficient and secure connectivity for multiple devices, while its compact and easy-to-install design makes it perfect for use in any indoor environment.
Features:
- Product Name: Gigabit Smart Switch
- Power Supply: External Power Adapter (Output: 12V DC, 1A)
- Network Media: 10BASE-T: UTP Category 3, 4, 5 Cable (Max 100m)
- Environment: Operating Temperature: 0℃~45℃ (32℉~113℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- MAC Address Table: 8K
- Type: Layer 2 switch
- Product Description: Smart switch desktop
- Layer: 2
Technical Parameters:
| SR-SG2226F |
| Power Supply | AC100~240V 50/60Hz |
| Standards | IEEE 802.3i,802.3u,802.3ab,802.3x,802.3az, 802.3z |
| Ports | 24×10/100/1000Mbps RJ45+2×SFP |
| Indicators | 24 electrical port speed indicators, 24 electrical port link/act indicators, power input indicator |
| Network Media (Cable) | 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum 100m)
1000Base-X:MMF,SMF |
| Dimensions | 440*190*44.5 mm |
| Transfer Method | Store-and-Forward |
| MAC Address Table | 8K |
| Switching Capacity | 52Gbps |
| Packet Forwarding Rate | 38.688Mpps |
| Packet Buffer | 4.1Mbit |
| Jumbo Frame | 10KBytes |
| Environment | Operating Temperature: 0℃ ~45℃ (0℉~113℉)
Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing |
Soft Features:
| L2 Switching Features | • IGMP Snooping
- Supports IGMP Snooping |
• Link Aggregation
- Supports static link aggregation |
| • Port Mirroring |
| • Cable Test |
| VLAN | • Supports up to 32 VLANs (out of 4K VLAN IDs |
| • MTU/Port/802.1Q VLAN |
Quality of Service
(QoS) | • Support Port-based/802.1p/DSCP priority |
| • Support 4 priority queues |
| • Storm Control |
| • Rate Limit |
| Management | • Web-based Graphic User Interface (GUI) • Smart-Configuration Utility |
| Ethernet Protocols | • IEEE 802.3 10BASE-T |
| • IEEE 802.3u 100BASE-TX/FX |
| • IEEE 802.3ab 1000BASE-T |
| • IEEE 802.3x Flow Control |
| • IEEE 802.1q VLANs/VLAN tagging |
| • IEEE 802.1p QoS |
Applications:
The Gigabit Smart Switch product offers a bandwidth of 52Gbps, which makes it ideal for use in scenarios that require high-speed data transfers. The switch comes with a MAC address table of 8K, which enables users to connect multiple devices to the network with ease. The Jumbo Frame feature with 9K Bytes capacity makes it easier to transmit large files, which is especially useful in a work environment where file sizes are often large.
The Gigabit Smart Switch product is also an excellent choice for use in smart switch desktop scenarios. It is easy to install and comes with a user-friendly interface, which makes it easier to manage and configure the switch settings. It is perfect for use in small to medium-sized businesses, as well as home environments.
In conclusion, the Gigabit Smart Switch product from Sirivision is a reliable and efficient option for layer 2 networking. Its features, including a high bandwidth, MAC address table, and Jumbo Frame support, make it an excellent choice for various scenarios. Its user-friendly interface also makes it a perfect fit for smart switch desktop scenarios.
Customization:
Brand Name: Sirivision
Place of Origin: Shenzhen,China
Dimensions ( W x D x H ): 440*190*44.5 mm
Environment: Operating Temperature: 0℃~45℃ (32℉~113℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Our customization services for the Sirivision Gigabit Smart Switch offer a range of options to meet your needs. Whether you require layer 2 networking, a layer 2 switch, or a smart switch, we can help you customize your product to ensure it meets your specific requirements.
FAQ:
Q: What is the brand name of this switch?
A: The brand name of this switch is Sirivision.
Q: Where is this switch manufactured?
A: This switch is manufactured in Shenzhen, China.
Q: Is this switch a Gigabit switch?
A: Yes, this switch is a Gigabit switch.
Q: Is this switch a managed switch or an unmanaged switch?
A: This switch is a managed switch.
Q: What kind of warranty does this switch come with?
A: We cannot provide warranty-related information as it is excluded from this prompt. Please refer to the product packaging or user manual for warranty information.
