Product Description:
The switch supports 8 10/100/1000 Mbps RJ45 ports, making it easy to connect devices such as desktop computers, printers, and servers. The network media supported by the switch includes UTP Category 3, 4, and 5 cable, with a maximum distance of 100m. The transmission method used by the switch is Store-and-Forward, ensuring that data is transmitted reliably and without errors.
The Gigabit Easy Smart Switch is a smart switch desktop device that is easy to set up and manage. The switch also supports VLANs, which enable you to segment your network and improve security by isolating different departments or groups of users.
Overall, the Gigabit Easy Smart Switch is a reliable and cost-effective solution for small networks that require simple and easy-to-use connectivity. Its Layer 2 networking capabilities, 8 10/100/1000 Mbps RJ45 ports, and support for the IEE802.3 protocol make it an ideal choice for small businesses and home offices looking to improve their network performance.
Features:
- Product Name: Gigabit Smart Switch
- Type: L2 Switch
- Network Media: 10BASE-T: UTP Category 3, 4, 5 Cable (Max 100m)
- MAC Address Table: 8K
- Dimensions (W x D x H): 225*135*35 mm
- Jumbo Frame: 9K Bytes
- Power Supply: External Power Adapter (Output: 12VDC/ 1A)
- Smart Managed: Yes
- Smart Switches for Home: Yes
Technical Parameters:
| SR-SG2210F-L |
| Power Supply | 12VDC/ 1A |
| Standards | IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab |
| Ports | 8×10/100/1000Mbps RJ45 ports, 2×SFP ports |
| Indicators | electrical port indicators, SFP fiber port indicators, power input indicator |
Network
medium | 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum 100m)
1000Base-X:MMF,SMF |
| Forwarding Mode | Store and Forward(Full Wire Speed) |
| Dimensions | 225*135*35 mm |
| Switching Capacity | 20Gbps |
| Packet Forwarding Rate | 14.88Mpps |
| MAC Address Table | 8K |
| Installation | Desktop installation |
| Packet Buffer | 1.5Mbit |
| Jumbo Frame | 9KBytes |
| Environment | Operating Temperature: 0℃ ~45℃ (0℉~113℉)
Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing |
Soft Features:
| L2 Switching Features | • IGMP Snooping
- Supports IGMP Snooping |
• Link Aggregation
- Supports static link aggregation |
| • Port Mirroring |
| • Cable Test |
| VLAN | • Supports up to 32 VLANs (out of 4K VLAN IDs |
| • MTU/Port/802.1Q VLAN |
Quality of Service
(QoS) | • Support Port-based/802.1p/DSCP priority |
| • Support 4 priority queues |
| • Storm Control |
| • Rate Limit |
| Management | • Web-based Graphic User Interface (GUI) • Smart-Configuration Utility |
| Ethernet Protocols | • IEEE 802.3 10BASE-T |
| • IEEE 802.3u 100BASE-TX/FX |
| • IEEE 802.3ab 1000BASE-T |
| • IEEE 802.3x Flow Control |
| • IEEE 802.1q VLANs/VLAN tagging |
| • IEEE 802.1p QoS |
Applications:
Customization:
Product Customization Services
Brand Name: Sirivision
Place of Origin: Shenzhen, China
Bandwidth: 20Gbps
Product Name: Gigabit Easy Smart Switch
Flow Control: IEEE 802.3x Flow Control
Transmission Method: Store-and-Forward
Our Gigabit Easy Smart Switch offers layer 2 networking and smart managed features, making it a reliable and efficient solution for your network needs. With a bandwidth of 20Gbps, you can expect fast and seamless data transmission. It also supports IEEE 802.3x Flow Control and uses the store-and-forward transmission method, ensuring the delivery of accurate and reliable data packets. Contact us to customize your Gigabit Easy Smart Switch to meet your specific requirements.
FAQ:
Q: What is the maximum number of ports on the Sirivision Gigabit Smart Switch?
A: The Sirivision Gigabit Smart Switch has a maximum of 8 ports.
Q: What is the maximum data transfer rate of the Sirivision Gigabit Smart Switch?
A: The Sirivision Gigabit Smart Switch has a maximum data transfer rate of 1 Gbps.
Q: How can I manage the Sirivision Gigabit Smart Switch?
A: The Sirivision Gigabit Smart Switch can be managed through a web-based interface.
Q: Where is the Sirivision Gigabit Smart Switch manufactured?
A: The Sirivision Gigabit Smart Switch is manufactured in Shenzhen, China.
