Product Description:
The Smart PoE Switch features LED indicators for power and link/activity, making it easy to monitor the switch and quickly diagnose any issues that may arise. The switch also supports QoS, enabling it to prioritize network traffic and ensure that mission-critical applications receive the bandwidth they require.
The Smart PoE Switch comes with an internal power, allowing the switch to provide power and data to up to 8 PoE+ devices. This makes it an excellent choice for businesses that need to power multiple PoE devices without the hassle of installing additional power outlets.
Port mirroring is another feature of the Smart PoE Switch that is useful for network troubleshooting and monitoring. With port mirroring, network administrators can mirror traffic from one port to another, allowing them to capture and analyze network traffic for performance and security issues.
In summary, the Smart PoE Switch is an excellent choice for businesses that require a reliable and efficient PoE+ switch. With its LED indicators, QoS support, internal power, and port mirroring, this switch provides everything that businesses need to manage their network effectively. Whether you need to power multiple PoE devices or prioritize network traffic, the Smart PoE Switch is the ideal solution for your business.
Features:
- Product Name: Gigabit Smart PoE Switch
- IGMP Snooping: Yes
- Network Protocols:
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- Power Supply: Internal Power
Technical Parameters:
| SR-SG2210FP |
| Power Supply | AC100~240V 50/60Hz |
| Standards | IEEE 802.3i,802.3u,802.3ab,802.3x,802.3at,802.3af,802.3z |
| Ports | 8 10,100,1000Mbps RJ45 ports, 2 Gigabit SFP fiber ports |
| Indicators | 8 electrical port speed indicators, 8 electrical port link/act indicators, power input indicator |
Network
medium | 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum 100m)
1000Base-X:MMF,SMF |
| Dimensions | 271*181.5*44.5 mm |
| PoE port | 8 802.3at/af standard POE |
| PoE Pin Definition | 1/2(+),3/6(-) |
| PoE power | 130 W |
| Total power | 150 W |
| Transfer Method | Store-and-Forward |
| MAC Address Table | 8K |
| Switching Capacity | 20Gbps |
| Packet Forwarding Rate | 14.88Mpps |
| Packet Buffer | 1.5Mbit |
| Jumbo Frame | 9KBytes |
| Environment | Operating Temperature: 0℃ ~45℃ (0℉~113℉)
Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing |
Soft Features:
| L2 Switching Features | • IGMP Snooping
- Supports IGMP Snooping |
• Link Aggregation
- Supports static link aggregation |
| • Port Mirroring |
| • Cable Test |
| VLAN | • Supports up to 32 VLANs (out of 4K VLAN IDs |
| • MTU/Port/802.1Q VLAN |
Quality of Service
(QoS) | • Support Port-based/802.1p/DSCP priority |
| • Support 4 priority queues |
| • Storm Control |
| • Rate Limit |
| Management | • Web-based Graphic User Interface (GUI) • Smart-Configuration Utility |
| Ethernet Protocols | • IEEE 802.3 10BASE-T |
| • IEEE 802.3u 100BASE-TX/FX |
| • IEEE 802.3ab 1000BASE-T |
| • IEEE 802.3x Flow Control |
| • IEEE 802.1q VLANs/VLAN tagging |
| • IEEE 802.1p QoS |
Applications:
With support for key network protocols such as IEEE 802.3, IEEE 802.3u, and IEEE 802.3ab, this PoE+ switch can be used in a wide range of scenarios. Whether you're setting up a small office network or a large-scale data center, the Smart PoE Switch has you covered.
One key advantage of this switch is its LED indicators, which make it easy to monitor its status and performance. The Power and Link/Activity indicators provide real-time feedback on the device's power supply and network connectivity, helping you to quickly diagnose and troubleshoot any issues that arise.
Another useful feature of the Smart PoE Switch is its ability to support port mirroring. This allows you to monitor network traffic by redirecting a copy of it from one port to another, making it an ideal solution for network analysis and troubleshooting.
Of course, one of the most important aspects of any PoE Ethernet switch is its power output, and the Smart PoE Switch doesn't disappoint in this regard. With a power output of 30W, it can easily power a range of devices such as IP cameras, VoIP phones, and wireless access points.
Finally, the Smart PoE Switch's store-and-forward switch architecture ensures that data is transmitted efficiently and accurately, making it a reliable choice for businesses and individuals alike.
Overall, the Smart PoE Switch from Sirivision is an excellent choice for anyone in need of a high-quality gigabit PoE switch. With its advanced features and reliable performance, it's sure to meet the needs of even the most demanding networking applications.
Customization:
Our Smart PoE Switch is powered by an internal power adapter, making it easy to use and install. With its gigabit poe switch capabilities, it is perfect for businesses and individuals who require high-speed data transfer rates.
FAQ:
Q: What is the brand name of this product?
A: The brand name of this product is Sirivision.
Q: Where is this product manufactured?
A: This product is manufactured in Shenzhen, China.
Q: What is the function of this Smart PoE Switch?
A: This Smart PoE Switch is designed to provide power and data transmission for network devices that support PoE (Power over Ethernet) technology.
Q: How many PoE ports does this switch have?
A: This switch comes with 8 PoE ports and 2 uplink ports.
Q: What is the maximum power output for each PoE port?
A: The maximum power output for each PoE port is 30W.
