Product Description:
The Gigabit Smart Switch is designed to operate in a wide range of environments. It can operate in temperatures ranging from 0℃ to 45℃ (32℉ to 113℉), making it ideal for use in a variety of settings. Its storage temperature range is -40℃ to 70℃ (-40℉ to 158℉), ensuring that it can be safely stored in a range of environments.
The Gigabit Smart Switch is powered by an internal power supply of AC100~240V 50/60Hz. This ensures that the switch is powered reliably and consistently, minimizing downtime and ensuring that your network is always up and running.
One of the key features of the Gigabit Smart Switch is its support for jumbo frames. With jumbo frame support of up to 9K bytes, this switch is able to handle larger data packets, reducing the workload on your network and improving overall performance.
Overall, the Gigabit Smart Switch is a powerful and reliable networking solution that is perfect for businesses and organizations of all sizes. Whether you need a switch for your home office or a large enterprise, the Gigabit Smart Switch has the features and capabilities you need to keep your network running smoothly.
Features:
- Product Name: Gigabit Easy Smart Switch
- Dimensions: 271*181.5*44.5 mm
- Interface: 8×10/100/1000Mbps RJ45+2×1000Mbps SFP
- MAC Address Table: 8K
- Great for smart switches for home or smart switch desktop use
Technical Parameters:
| SR-SG2210F |
| Power Supply | AC100~240V 50/60Hz |
| Standards | IEEE 802.3i,802.3u,802.3ab,802.3x,802.3z |
| Ports | 8 10,100,1000Mbps RJ45 ports, 2 Gigabit optical ports |
| Indicators | 8 electrical port Gigabit speed indicators, 8 electrical port link/act indicators, power input indicator |
Network
medium | 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum 100m)
1000Base-X:MMF,SMF |
| Dimensions | 271*181.5*44.5 mm |
| Transfer Method | Store-and-Forward |
| MAC Address Table | 8K |
| Switching Capacity | 20Gbps |
| Packet Forwarding Rate | 14.88Mpps |
| Packet Buffer | 1.5Mbit |
| Jumbo Frame | 9KBytes |
| Environment | Operating Temperature: 0℃ ~45℃ (32℉~113℉)
Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing |
Smart switches for home, layer 2 networking, layer 2 networking
Soft Features:
| L2 Switching Features | • IGMP Snooping
- Supports IGMP Snooping |
• Link Aggregation
- Supports static link aggregation |
| • Port Mirroring |
| • Cable Test |
| VLAN | • Supports up to 32 VLANs (out of 4K VLAN IDs |
| • MTU/Port/802.1Q VLAN |
Quality of Service
(QoS) | • Support Port-based/802.1p/DSCP priority |
| • Support 4 priority queues |
| • Storm Control |
| • Rate Limit |
| Management | • Web-based Graphic User Interface (GUI) • Smart-Configuration Utility |
| Ethernet Protocols | • IEEE 802.3 10BASE-T |
| • IEEE 802.3u 100BASE-TX/FX |
| • IEEE 802.3ab 1000BASE-T |
| • IEEE 802.3x Flow Control |
| • IEEE 802.1q VLANs/VLAN tagging |
| • IEEE 802.1p QoS |
Applications:
The switch comes equipped with 8 10/100/1000 Mbps RJ45 Ports, which allows for seamless connectivity. This L2 switch is designed to improve the efficiency of layer 2 networking, making it an essential tool for businesses that require high-speed data transfer.
The product is perfect for a variety of occasions and scenarios. For instance, it can be used in a small office setup where the need for high-speed data transfer is paramount. This switch can be used to connect multiple devices, such as printers, scanners, and computers, to the network for seamless data transfer. It can also be used in a medium-sized business setup where the demand for high-speed data transfer is even higher. In this scenario, the switch's 20Gbps bandwidth is perfect for ensuring that data transfer is as fast as possible.
The Gigabit Smart Switch can also be used in a variety of other scenarios, such as in a school or a retail store. In a school, the switch can be used to connect multiple devices, such as computers and projectors, to the network for seamless data transfer. In a retail store, the switch can be used to connect multiple point-of-sale devices to the network for seamless transaction processing.
In conclusion, Sirivision's Gigabit Smart Switch is a highly efficient and reliable L2 switch that is perfect for small and medium-sized businesses. Its high bandwidth, compact dimensions, and easy installation make it an essential tool for businesses that require high-speed data transfer. It is perfect for a variety of occasions and scenarios and is designed to improve the efficiency of layer 2 networking.
FAQ:
Q1: What is the brand name of this Gigabit Smart Switch?
A1: The brand name of this Gigabit Smart Switch is Sirivision.
Q2: Where is this Gigabit Smart Switch manufactured?
A2: This Gigabit Smart Switch is manufactured in Shenzhen, China.
Q3: How many ports does this Gigabit Smart Switch have?
A3: This Gigabit Smart Switch has10 ports.
Q5: Does this Gigabit Smart Switch support VLAN?
A5: Yes, this Gigabit Smart Switch supports VLAN.
